Push Pull
Push-pull forklit attachment, Suitable for container operation.
Through the use of thin skateboard to achieve more economic shipping operations according to different work, needs can be divided into slip sheet retention and non-retention, then realization of the push and pull back goods, simple operation.
Confirm the slip sheet and receiving operation before buying a push-pull
A push-pull attachment handles a compatible slip-sheeted load by gripping the sheet tab and transferring the load over its platens. The load, sheet and receiving operation must work together for palletless handling to be useful.
ForkFocus can compare sheet-retention and non-retention requirements for container or warehouse work. The right choice depends on where the sheet should remain after the load is deposited and how the next handling stage will receive it.
Make the whole transfer compatible
Show the sheet material, tab dimensions, load footprint and load assembly. A weak or damaged tab, an unstable load or an incompatible receiving surface can prevent the intended transfer even when the attachment has enough nominal capacity.
If palletized and slip-sheeted loads are mixed, describe both tasks. Confirm the intended mounting arrangement and whether the proposed attachment can perform each required operation rather than assuming every push-pull has the same functions.
| Purchase item | What to specify | Why it matters |
|---|---|---|
| Slip sheet | Material, dimensions, tab arrangement and condition. | Checks the gripper interface for the sheets used by both shipping and receiving parties. |
| Load assembly | Weight, footprint, package stability and required support. | Checks that the goods can transfer onto and off the platens. |
| Sheet handling | Retention or non-retention and the destination receiving method. | Identifies where the sheet must remain after each transfer. |
| Forklift installation | Carriage or fork mounting, hydraulics, mast and residual capacity. | Checks the attachment and truck as a complete installation. |
Details about Push Pull
- For easy push, pull and stable action, the hydraulic control system is eqqipped with double overflow control.
- The shaft sleeves is equipped with self lubricating function and can be use without adding grease manually witha very long duration.
- All pins and shafts of the pull push attachment is of a very high quiality materials therefore, they are subjected to material treatments and chrome palating on the surface providing abration and corrosion resistance and with a much higher strength impact.
- To enhance the bearing capacity and and impact resistance, the hanging part is equipped with cast staeel structure.
Technical details
Customized push pull forklift attachment available.
Just tell us your specific requirement, or give us the sample model information. We will tailor made that.
typical industry
- Factory；
- Shipping.
Three basic information provided for a correct quote:
- Forklift load capacity;
- Cargo weight;
- Other special request if needed.
