Carton clamp
Carton Clamps attachments are for secure and safe handling of household appliances like washing machines, refrigerators, televisions, etc.
It can also handle goods like wine packaged foods or materials like chemicals or plastics.
This attachment is used in plants and warehouses for sensitive goods with a stated capacity of up to 2,000 kg. Package strength, full-length contact and clamping pressure must be checked for the actual cartons.
Select carton contact pads for the package, not only its weight
A carton clamp can handle appliances and packaged goods without a pallet when the package can tolerate the required side contact. Pad area, package strength and the load arrangement matter as much as attachment capacity.
ForkFocus can review a refrigerator carton, an appliance stack or another packaged load against its dimensions and contact surfaces. This helps you buy a clamp that holds the goods while respecting the packaging limits.
Show the full load arrangement in the enquiry
A single appliance carton and several stacked cartons behave differently under the same pad contact. Show the number of units, stacking pattern, wrapping and the faces that will be clamped; note any package handling instructions.
Agree the contact-pad specification and pressure-control assessment for representative goods. A higher hydraulic pressure or a larger nominal clamp rating does not by itself prove that a sensitive carton will avoid crushing or slipping.
| Purchase item | What to specify | Why it matters |
|---|---|---|
| Load pattern | Single unit or multiple units, overall dimensions and maximum weight. | Checks arm opening, contact coverage and how the package stack is supported. |
| Package construction | Carton board, wrapping, rigidity and any marked handling limits. | Supports a clamping assessment for the actual goods rather than a generic carton. |
| Pad and arm arrangement | Pad dimensions, contact material and access between adjacent loads. | Balances retention, package protection and pickup clearance. |
| Truck and hydraulics | Carriage, lift height, load centre, pressure, flow and functions. | Checks the complete forklift installation and residual capacity. |
Details about Carton clamp
Why full-length arm contact matters for appliance cartons
One carton per gripUsable arm and pad contact length ≥ the longest carton length in the arm direction.
Carton
Two cartons along the armPlan at least 2 × the maximum single-carton length, plus any gap between cartons.
Carton 1Carton 2
Measure usable pad contact length, not only the steel arm. Send ForkFocus the longest carton length, one- or two-carton pickup pattern, package photos or internal-support drawing, and maximum weight. We can check arm length, pad material, clamping pressure and the forklift’s installed capacity. A representative package trial is still needed before approving the handling method.
- The increased structural design of the carton clamp makes an excellent view, with the T-shaped sliding pair acquiring a very high strength and uniform stress.
- The arm design of the carton clamp makes it very easy for wedging the goods tightly.
- It also has a self-lubricating function which is installed firmly and reliably.
- The movement of the carton clamp is run by the valve body therefore facilitating it’s operations.
Size The Pads For Two Cartons Along The Arm
For two cartons along the arm, assess the combined contact length. A pad that supports one carton may stop part-way along the second. Force can then be concentrated on an unsupported package area instead of being distributed over both intended side faces.
| Operating Difference | Selection Consequence |
|---|---|
| Full side-face contact | Check the longest carton against usable pad length and the permitted contact faces. |
| Several cartons in height | Review the complete stack, the least-supported carton and the package compression limit. |
| Pressure setting | Use the actual packaging and load pattern to assess retention and deformation. Neither maximum supply pressure nor attachment rating defines the setting. |
Apply this to the goods you actually handle. For an illustrative carton length of 900 mm, two cartons along the arm require at least 1,800 mm of effective contact length before adding any necessary separation. Measure the usable contact pad, not merely the outside steel-arm length.
ForkFocus can compare these requirements with the attachment and forklift installation already described on this page. Send the photos or measurements you have. Complete technical specifications are not a first-contact requirement.
Technical details
Customized carton clamp attachment available. Just tell us your specific requirement, or give us the sample model information. We will tailor made that.
typical industry
- household appliance industry；
- Plastic industry;
- Warehouse;
- Shipping.
Three basic information provided for a correct quote:
- Forklift load capacity;
- Cargo weight;
- Carton clamp opening range you need.
Except above three basic information, it’d be perfect to know the outer packing material type.
